| Kode Beep Bios Komputer |
Kode Beep BIOS AMI
| Beeps | Error Message | Description |
1 short | DRAM refresh failure | The programmable interrupt timer or programmable interrupt controller has probably failed |
2 short | Memory parity error | A memory parity error has occurred in the first 64K of RAM. The RAM IC is probably bad |
3 short | Base 64K memory failure | A memory failure has occurred in the first 64K of RAM. The RAM IC is probably bad |
4 short | System timer failure | The system clock/timer IC has failed or there is a memory error in the first bank of memory |
5 short | Processor error | The system CPU has failed |
6 short | Gate A20 failure | The keyboard controller IC has failed, which is not allowing Gate A20 to switch the processor to protected mode. Replace the keyboard controller |
7 short | Virtual mode processor exception error | The CPU has generated an exception error because of a fault in the CPU or motherboard circuitry |
8 short | Display memory read/write error | The system video adapter is missing or defective |
9 short | ROM checksum error | The contents of the system BIOS ROM does not match the expected checksum value. The BIOS ROM is probably defective and should be replaced |
10 short | CMOS shutdown register read/write error | The shutdown for the CMOS has failed |
11 short | Cache error | The L2 cache is faulty |
1 long, 2 short | Failure in video system | An error was encountered in the video BIOS ROM, or a horizontal retrace failure has been encountered |
1 long, 3 short | Memory test failure | A fault has been detected in memory above 64KB |
1 long, 8 short | Display test failure | The video adapter is either missing or defective |
2 short | POST Failure | One of the hardware testa have failed |
1 long | POST has passed all tests |
Kode Beep BIOS Compaq
Beeps | Error Message | Description |
1 short | No error | System is booting properly |
1 long, 1 short | BIOS ROM checksum error | The contents of the BIOS ROM to not match the expected contents. If possible, reload the BIOS from the PAQ |
2 short | General error | Unknown |
1 long, 2 short | Video error | Check the video adapter and ensure it's seated properly. If possible, replace the video adapter |
7 beeps (1 long, 1s, 1l, 1 short, pause, 1 long, 1 short, 1 short | AGP video | The AGP video card is faulty. Reseat the card or replace it outright. This beep pertains to Compaq Deskpro systems |
1 long neverending beep | Memory error. Bad RAM. Replace and test | |
1 short, 2 long | Bad RAM | Reseat RAM then retest; replace RAM if failure continues |
Kode Beep BIOS IBM Desktop
| Beeps | Error Message | Description |
1 short | Normal POST | System is booting properly |
2 short | Initialization error | Error code is displayed |
1 long, 1 short | System board error | |
1 long, 2 short | Video adapter error | |
1 long, 3 short | EGA/VGA adapter error | |
3 long | 3270 keyboard adapter error | |
Continuous | Power supply error | Replace the power supply |
999s | Power supply error | Replace the power supply |
No beep | Power supply | Replace the power supply |
Kode Beep BIOS IBM Thinkpad
| Beeps/Error | Description |
Continuous beeping | System board failure |
One beep; Unreadable, blank or flashing LCD | LCD connector problem; LCD backlight inverter failure; video adapter faulty; LCD assembly faulty; System board failure; power supply failure |
One beep; Message "Unable to access boot source" | Boot device failure; system board failure |
One long, two short beeps | System board failure; Video adapter problem; LCD assembly failure |
One long, four short beeps | Low battery voltage |
One beep every second | Low battery voltage |
Two short beeps with error codes | POST error message |
Two short beeps | System board failure |
Kode Beep BIOS Phoenix ISA/MCA/EISA
The beep codes are represented in the number of beeps. E.g. 1-1-2 would mean 1 beep, a pause, 1 beep, a pause, and 2 beeps.
With a Dell computer, a 1-2 beep code can also indicate that a bootable add-in card is installed but no boot device is attached. For example, in you insert a Promise Ultra-66 card but do not connect a hard drive to it, you will get the beep code. I verified this with a SIIG (crap -- avoid like the plague) Ultra-66 card, and then confirmed the results with Dell. Submitted by John Palmer.
| Beeps | Error Message | Description |
1-1-2 | CPU test failure | The CPU is faulty. Replace the CPU |
Low 1-1-2 | System board select failure | The motherboard is having an undetermined fault. Replace the motherboard |
1-1-3 | CMOS read/write error | The real time clock/CMOS is faulty. Replace the CMOS if possible |
Low 1-1-3 | Extended CMOS RAM failure | The extended portion of the CMOS RAM has failed. Replace the CMOS if possible |
1-1-4 | BIOS ROM checksum error | The BIOS ROM has failed. Replace the BIOS or upgrade if possible |
1-2-1 | PIT failure | The programmable interrupt timer has failed. Replace if possible |
1-2-2 | DMA failure | The DMA controller has failed. Replace the IC if possible |
1-2-3 | DMA read/write failure | The DMA controller has failed. Replace the IC if possible |
1-3-1 | RAM refresh failure | The RAM refresh controller has failed |
1-3-2 | 64KB RAM failure | The test of the first 64KB RAM has failed to start |
1-3-3 | First 64KB RAM failure | The first RAM IC has failed. Replace the IC if possible |
1-3-4 | First 64KB logic failure | The first RAM control logic has failed |
1-4-1 | Address line failure | The address line to the first 64KB RAM has failed |
1-4-2 | Parity RAM failure | The first RAM IC has failed. Replace if possible |
1-4-3 | EISA fail-safe timer test | Replace the motherboard |
1-4-4 | EISA NMI port 462 test | Replace the motherboard |
2-1-1 | 64KB RAM failure | Bit 0; This data bit on the first RAM IC has failed. Replace the IC if possible |
2-1-2 | 64KB RAM failure | Bit 1; This data bit on the first RAM IC has failed. Replace the IC if possible |
2-1-3 | 64KB RAM failure | Bit 2; This data bit on the first RAM IC has failed. Replace the IC if possible |
2-1-4 | 64KB RAM failure | Bit 3; This data bit on the first RAM IC has failed. Replace the IC if possible |
2-2-1 | 64KB RAM failure | Bit 4; This data bit on the first RAM IC has failed. Replace the IC if possible |
2-2-2 | 64KB RAM failure | Bit 5; This data bit on the first RAM IC has failed. Replace the IC if possible |
2-2-3 | 64KB RAM failure | Bit 6; This data bit on the first RAM IC has failed. Replace the IC if possible |
2-2-4 | 64KB RAM failure | Bit 7; This data bit on the first RAM IC has failed. Replace the IC if possible |
2-3-1 | 64KB RAM failure | Bit 8; This data bit on the first RAM IC has failed. Replace the IC if possible |
2-3-2 | 64KB RAM failure | Bit 9; This data bit on the first RAM IC has failed. Replace the IC if possible |
2-3-3 | 64KB RAM failure | Bit 10; This data bit on the first RAM IC has failed. Replace the IC if possible |
2-3-4 | 64KB RAM failure | Bit 11; This data bit on the first RAM IC has failed. Replace the IC if possible |
2-4-1 | 64KB RAM failure | Bit 12; This data bit on the first RAM IC has failed. Replace the IC if possible |
2-4-2 | 64KB RAM failure | Bit 13; This data bit on the first RAM IC has failed. Replace the IC if possible |
2-4-3 | 64KB RAM failure | Bit 14; This data bit on the first RAM IC has failed. Replace the IC if possible |
2-4-4 | 64KB RAM failure | Bit 15; This data bit on the first RAM IC has failed. Replace the IC if possible |
3-1-1 | Slave DMA register failure | The DMA controller has failed. Replace the controller if possible |
3-1-2 | Master DMA register failure | The DMA controller had failed. Replace the controller if possible |
3-1-3 | Master interrupt mask register failure | The interrupt controller IC has failed |
3-1-4 | Slave interrupt mask register failure | The interrupt controller IC has failed |
3-2-2 | Interrupt vector error | The BIOS was unable to load the interrupt vectors into memory. Replace the motherboard |
3-2-3 | Reserved | |
3-2-4 | Keyboard controller failure | The keyboard controller has failed. Replace the IC if possible |
3-3-1 | CMOS RAM power bad | Replace the CMOS battery or CMOS RAM if possible |
3-3-2 | CMOS configuration error | The CMOS configuration has failed. Restore the configuration or replace the battery if possible |
3-3-3 | Reserved | |
3-3-4 | Video memory failure | There is a problem with the video memory. Replace the video adapter if possible |
3-4-1 | Video initialization failure | There is a problem with the video adapter. Reseat the adapter or replace the adapter if possible |
4-2-1 | Timer failure | The system's timer IC has failed. Replace the IC if possible |
4-2-2 | Shutdown failure | The CMOS has failed. Replace the CMOS IC if possible |
4-2-3 | Gate A20 failure | The keyboard controller has failed. Replace the IC if possible |
4-2-4 | Unexpected interrupt in protected mode | This is a CPU problem. Replace the CPU and retest |
4-3-1 | RAM test failure | System RAM addressing circuitry is faulty. Replace the motherboard |
4-3-3 | Interval timer channel 2 failure | The system timer IC has failed. Replace the IC if possible |
4-3-4 | Time of day clock failure | The real time clock/CMOS has failed. Replace the CMOS if possible |
4-4-1 | Serial port failure | A error has occurred in the serial port circuitry |
4-4-2 | Parallel port failure | A error has occurred in the parallel port circuitry |
4-4-3 | Math coprocessor failure | The math coprocessor has failed. If possible, replace the MPU |
| Beeps | Description |
1-1-1-3 | Verify real mode |
1-1-2-1 | Get CPU type |
1-1-2-3 | Initialize system hardware |
1-1-3-1 | Initialize chipset registers with initial values |
1-1-3-2 | Set in POST flag |
1-1-3-3 | Initialize CPU registers |
1-1-4-1 | Initialize cache to initial values |
1-1-4-3 | Initialize I/O |
1-2-1-1 | Initialize power management |
1-2-1-2 | Load alternative registers with initial POST values |
1-2-1-3 | Jump to UserPatch0 |
1-2-2-1 | Initialize timer initialization |
1-2-3-1 | 8254 timer initialization |
1-2-3-3 | 8237 DMA controller initialization |
1-2-4-1 | Reset Programmable Interrupt Controller |
1-3-1-1 | Test DRAM refresh |
1-3-1-3 | Test 8742 Keyboard Controller |
1-3-2-1 | Set ES segment register to 4GB |
1-3-3-1 | Autosize DRAM |
1-3-3-3 | Clear 512K base memory |
1-3-4-1 | Test 512K base address lines |
1-3-4-3 | Test 51K base memory |
1-4-1-3 | Test CPU bus-clock frequency |
1-4-2-1 | CMOS RAM read/write failure (this commonly indicates a problem on the ISA bus such as a card not seated) |
1-4-2-4 | Reinitialize the chipset |
1-4-3-1 | Shadow system BIOS ROM |
1-4-3-2 | Reinitialize the cache |
1-4-3-3 | Autosize the cache |
1-4-4-1 | Configure advanced chipset registers |
1-4-4-2 | Load alternate registers with CMOS values |
2-1-1-1 | Set initial CPU speed |
2-1-1-3 | Initialize interrupt vectors |
2-1-2-1 | Initialize BIOS interrupts |
2-1-2-3 | Check ROM copyright notice |
2-1-2-4 | Initialize manager for PCI Options ROMs |
2-1-3-1 | Check video configuration against CMOS |
2-1-3-2 | Initialize PCI bus and devices |
2-1-3-3 | initialize all video adapters in system |
2-1-4-1 | Shadow video BIOS ROM |
2-1-4-3 | Display copyright notice |
2-2-1-1 | Display CPU type and speed |
2-2-1-3 | Test keyboard |
2-2-2-1 | Set key click if enabled |
2-2-2-3 | Enable keyboard |
2-2-3-1 | Test for unexpected interrupts |
2-2-3-3 | Display prompt "Press F2 to enter setup" |
2-2-4-1 | Test RAM between 512K and 640K |
2-3-1-1 | Test expanded memory |
2-3-1-3 | Test extended memory address lines |
2-3-2-1 | Jump to UserPatch1 |
2-3-2-3 | Enable external and CPU caches |
2-3-2-3 | Configure advanced cache registers |
2-3-3-1 | Enable external and CPU caches |
2-3-3-2 | Initialize SMI handler |
2-3-3-3 | Display external cache size |
2-3-4-1 | Display shadow message |
2-3-4-3 | Display non-disposable segments |
2-4-1-1 | Display error messages |
2-4-1-3 | Check for configuration errors |
2-4-2-1 | Test real-time clock |
2-4-2-3 | Check for keyboard errors |
2-4-4-1 | Setup hardware interrupt vectors |
2-4-4-3 | Test coprocessor if present |
3-1-1-1 | Disable onboard I/O ports |
3-1-1-3 | Detect and install external RS232 ports |
3-1-2-1 | Detect and install external parallel ports |
3-1-2-3 | Reinitialize onboard I/O ports |
3-1-3-1 | Initialize BIOS Data Area |
3-1-3-3 | Initialize Extended BIOS Data Area |
3-1-4-1 | Initialize floppy controller |
3-2-1-1 | Initialize hard disk controller |
3-2-1-2 | Initialize local bus hard disk controller |
3-2-1-3 | Jump to UserPatch2 |
3-2-2-1 | Disable A20 address line |
3-2-2-3 | Clear huge ES segment register |
3-2-3-1 | Search for option ROMs |
3-2-3-3 | Shadow option ROMs |
3-2-4-1 | Setup power management |
3-2-4-3 | Enable hardware interrupts |
3-3-1-1 | Set time of day |
3-3-1-3 | Check key lock |
3-3-3-1 | Erase F2 prompt |
3-3-3-3 | Scan for F2 keystroke |
3-3-4-1 | Enter SETUP |
3-3-4-3 | Clear in-POST flag |
3-4-1-1 | Check for errors |
3-4-1-3 | POST done - prepare to boot operating system |
3-4-2-1 | One beep |
3-4-2-3 | Check password (optional) |
3-4-3-1 | Clear global descriptor table |
3-4-4-1 | Clear parity checkers |
3-4-4-3 | Check virus and backup reminders |
4-1-1-1 | Try to boot with INT 19 |
4-2-1-1 | Interrupt handler error |
4-2-1-3 | Unknown interrupt error |
4-2-2-1 | Pending interrupt error |
4-2-2-3 | Initialize option ROM error |
4-2-3-1 | Shutdown error |
4-2-3-3 | Extended Block Move |
4-2-4-1 | Shutdown 10 error |
4-2-4-3 | Keyboard Controller failure (most likely problem is with RAM or cache unless no video is present) |
4-3-1-3 | Initialize the chipset |
4-3-1-4 | Initialize refresh counter |
4-3-2-1 | Check for Forced Flash |
4-3-2-2 | BIOS ROM is OK |
4-3-2-4 | Do a complete RAM test |
4-3-3-1 | Do OEM initialization |
4-3-3-2 | Initialize interrupt controller |
4-3-3-3 | Read in bootstrap code |
4-3-3-4 | Initialize all vectors |
4-3-4-2 | Initialize the boot device |
4-3-4-3 | Boot code was read OK |
